Renewal 201 Latest Exam For TMOS Administration Certification

NEW QUESTION 1
A 8IG-IP Administrator configures a node with a standard icmp Health Monitor. The Node shows as DOWN although the Backend Server is configured to answer ICMP requests. Which step should the administrator take next to find the root cause of this issue?

• A. Run a curl Run a qkview
• B. Run a qkview
• C. Runatcpdump
• D. Runanssldump

Answer: C

NEW QUESTION 2
Assume a virtual server is configured with a ClientSSL profile. What would the result be if the virtual server's destination port were not 443?

• A. SSL termination could not be performed if the virtual server's port was not port 443.
• B. Virtual servers with a ClientSSL profile are always configured with a destination port of 443.
• C. As long as client traffic was directed to the alternate port, the virtual server would work as intended.
• D. Since the virtual server is associated with a ClientSSL profile, it will always process traffic sent to port 443.

Answer: C

NEW QUESTION 3
When upgrading a BIG-IP redundant pair, what happens when one system has been updated but the other has not?

• A. Synching should not be performed.
• B. The first system to be updated will assume the Active role.
• C. This is not possible since both systems are updated simultaneously.
• D. The older system will issue SNMP traps indicating a communication error with the partner.

Answer: A

NEW QUESTION 4
A VLAN has the following objects configured:
Self-IP 10.10.10.100 with port lockdown set to Allow default Virtual server 10.10.10.100:443 with UDP profile enabled Virtual server 10.10.10.0/24 port forwarding virtual server
Global destination NAT forwarding 10.10.10.100 to internal server 172.168.10.100
Which object will process this request when https://10.10.10.100 is entered into a browser?

• A. self-IP 10.10.10.100 with port lockdown set to Allow default
• B. virtual server 10.10.100/24 port o forwarding virtual server
• C. global destination NAT forwarding 10.10.10.100 to internal server 172.168.10.100
• D. virtual server 10.10.10.100.443 with UDP profile enabled

Answer: A

NEW QUESTION 5
A BIG-IP Administrator needs to purchase new licenses for a BIG-IP appliance.
The administrator needs to know if a module is licensed and the memory requirement for that module. Where should the administrator view this information in the System menu?

• A. Resource Provisioning
• B. Configuration > Device
• C. Software Management
• D. Configuration >OVSDB

Answer: A

NEW QUESTION 6
A 8IG-IP device is replaced with an RMA device. The BIG-IP Administrator renews the license and tries to restore the configuration from a previously generated UCS archive on the RMA device. The device configuration is NOT fully loading. What is causing the configuration load to fail?

• A. The Device Group is NOT configured for Full Sync.
• B. The US does NOT contain the full config
• C. The clock is NOT set correctly
• D. The Master Key is NOT restored

Answer: D

NEW QUESTION 7
A BIG-IP Administrator must configure the BIG-IP device to send system log messages to a remote syslog server In addition, the log messages need to be sent over TCP for guaranteed delivery. What should the BIG-IP Administrator configure?

• A. syslog-ng
• B. Request Logging Profile
• C. HSL Logging
• D. Remote Logging

Answer: D

NEW QUESTION 8
How should a BIG-IP Administrator persistent sessions from being sent to a pool member so that the server administrator can perform maintenance?

• A. force the pool member offline
• B. disable the pool member
• C. add an additional monitor to the poor
• D. disable the virtual server

Answer: A

NEW QUESTION 9
Refer to the exhibit.
Which TMSH command generated this output?

• A. tmsh list /cm sync-status
• B. tmsh show /sys sync-status
• C. tmsh list /sys sync-status
• D. tmsh show /cm sync status

Answer: D

NEW QUESTION 10
How is persistence configured?

• A. Persistence is an option within each pool's definition.
• B. Persistence is a profile type; an appropriate profile is created and associated with virtual server.
• C. Persistence is a global setting; once enabled, loadbalancing choices are superceded by the persistence method that is specified.
• D. Persistence is an option for each pool membe
• E. When a pool is defined, each member's definition includes the option for persistence.

Answer: B

NEW QUESTION 11
What is the purpose of floating self-IP addresses?

• A. to define an address that grants administrative access to either system at any time
• B. to define an address that allows either system to initiate communication at any time
• C. to define an address that allows network devices to route traffic via a single IP address
• D. to define an address that gives network devices greater flexibility in choosing a path to forward traffic

Answer: C

NEW QUESTION 12
A BIG-IP Administrator runs the initial configuration wizard and learns that the NTP servers were invalid. In which area of the Configuration Utility should the BIG-IP Administrator update the list of configured NTP servers?

• A. System > Configuration
• B. System > Services
• C. System > Preferences
• D. System > Platform

Answer: A

NEW QUESTION 13
The current status of a given pool is offline (red). Which condition could explain that state? Assume the descriptions below include all monitors assigned for each scenario.

• A. No monitors are currently assigned to any pool, member or node.
• B. The pool has a monitor assigned to it, and none of the pool members passed the test.
• C. The pool has a monitor assigned to it, and only some of the pool's members passed the test.
• D. A monitor is assigned to all nodes and all nodes have passed the tes
• E. The pool's members have no specific monitor assigned to them.

Answer: B

NEW QUESTION 14
Refer to the exhibit.

A pool member fails the monitor checks for about 30 minutes and then starts passing the monitor checks. New traffic is Not being sent to the pool member.
What is the likely reason for this problem?

• A. The pool member is disabled
• B. Monitor Type is TCP Half Open
• C. Manual resume is enabled
• D. Time Until Up is zero

Answer: C

NEW QUESTION 15
The ICMP monitor has been assigned to all nodes. In addition, all pools have been assigned custom monitors. The pool is marked available. If a pool is marked available (green) which situation is sufficient to cause this?

• A. All of the pool member nodes are responding to the ICMP monitor as expected.
• B. Less than 50% of the pool member nodes responded to the ICMP echo request.
• C. All of the members of the pool have had their content updated recently and their responses no longer match the monitor.
• D. Over 25% of the pool members have had their content updated and it no longer matches the receive rule of the custom monito
• E. The other respond as expected.

Answer: D

NEW QUESTION 16
The owner of a web application asks the 8IG-IP Administrator to change the port that the BIG-IP device sends traffic to. This change must be made for each member in the server pool named app_pool for their Virtual Server named app_vs. In which area of the BIG-IP Configuration Utility should the BIG-P Administrator make this change?

• A. Local Traffic > Pools
• B. Local Traffic > Nodes
• C. Network > Interfaces
• D. Local Traffic > Virtual Servers

Answer: A

NEW QUESTION 17
Refer to the exhibit.

A BIG-IP Administrator needs to configure health monitors for a newly configured server pool named Pool_B.
Which health monitor settings will ensure that all pool members will be accurately marked as available or unavailable?

• A. HTTPS, HTTP, FTP, and ICMP, with the Availability Requirement of all health monitors
• B. HTTPS, HTTP, FTP, and SSH, with the Availability Requirement of at least one monitor
• C. HTTPS and HTTP with the Availability Requirement of at least one health monitor
• D. HTTPS, HTTP, FTP, and SSH with the Availability Requirement of all health monitors

Answer: B

Explanation:
From the port, the four members are HTTP, FTP, HTTPS, and SSH applications. If you want to monitor at the same time, you must configure at least one.

NEW QUESTION 18
Refer to the exhibit.

An organization is reporting slow performance accessing their Intranet website, hosted in a public cloud. All employees use a single Proxy Server with the public IP of 104.219.110.168 to connect to the Internet. What should the BIG-IP Administrator of the Intranet website do to fix this issue?

• A. Change Source Address to 104.219.110.168/32
• B. Change Load Balancing Method to Least Connection
• C. Change Fallback Persistence Profile to source_addr
• D. Change Default Persistence Profile to cookie

Answer: D

NEW QUESTION 19
An LTM device has a virtual server mapped to www.f5.com with a pool assigned. Users report that when browsing, they are periodically required to re-login to /resources/201.1.7.b.2_l.com. The objects are defined as follows:
Virtual server. Destination 192.168.245.100:443 netmask 255.255.255.0 Persistence: SSL session persistence
Profiles: HTTP/TCP
Which persistence method should the BIG-IP Administrator apply to resolve this issue?

• A. Source address affinity
• B. hexadecimal
• C. SIP
• D. Destination address affinity

Answer: A

NEW QUESTION 20
A Standard Virtual Server for a web application is configured with Automap for the Source Address Translation option. The original source address of the client must be known by the backend servers. What should the BIG-IP Administrator configure to meet this requirement?

• A. The Virtual Server type as Performance (HTTP)
• B. An HTTP profile to insert the X-Forward-For header
• C. An HTTP Transparent profile
• D. A SNAT Pool with the client IP

Answer: B

Explanation:
Because it is a web application, you can insert the source IP in the xff field in the http profile.
